Cisco QSFP-40G-UNIV Compatible 40GBASE-UNIV QSFP+ Optical Transceiver Module for Ethernet and Data Center (SMF/MMF, 1310nm, 150m/2km, LC, DOM)

Application: 40G Ethernet over MMF and SMF, Data Center
CDR: None
Cisco Compatible: QSFP-40G-UNIV
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 3.5dB
Form Factor: QSFP+
Max Cable Distance: 150m@OM3 MMF, 2km@SMF
Max Data Rate: 41.2Gbps
Media: SMF/MMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget(MMF): 3.5dB
Powerbudget(SMF): 0.5dB
Power Consumption: 3.5W
Protocols: 40G Ethernet, MSA Compliant
Receiver Sensitivity: <-10dBm
Receiver Type: PIN
Transimitter Type: DFB CWDM
Transmit and Dispersion Penalty(MMF): 4.7dB
Transmit and Dispersion Penalty(SMF): 2.6dB
TX Power: -7~2.3dBm
Wavelength: 1310nm
