Cisco DWDM-SFP25G-56.55 Compatible 25G DWDM SFP28 100GHz Optical Transceiver Module for Data Center and Telecom (SMF, 1556.55nm, 10km, LC, DOM)

Application: 25GBASE Ethernet, Data Center, Telecom
CDR: TX and RX
Cisco Compatible: DWDM-SFP25G-56.55
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 4dB
Form Factor: SFP28
Max Cable Distance: 10km
Max Data Rate: 25.78Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 10dB
Power Consumption: 2W
Protocols: MSA Compliant, CPRI, eCPRI
Receiver Sensitivity: <-12dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 3.5dB
Transmitter Type: EML DWDM
TX Power: -2~6dBm
Wavelength: 1556.55nm
