Cisco QDD-400G-DR4-S Compatible 400GBASE-DR4 QSFP-DD PAM4 1310nm 500m DOM Transceiver Module (SMF, 1310nm, 500m, MTP/MPO, DOM)

Application: 400GBASE Data Center
Cisco Compatible: QDD-400G-DR4-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: MTP/MPO-12
DDM/DOM: Supported
Electric Signal: 8x50G
Form Factor: QSFP-DD
Max Cable Distance: 500m
Max Data Rate: 400Gbps
Media: SMF
Modulation Format: PAM4
Optical Signal: 4x100G
Power Consumption: <12W
Protocols: QSFP-DD MSA Compliant
Receiver Sensitivity: <-1.9dBm
Receiver Type: PIN
Transmitter Type: 1310nm EML
TX Power: -2.9~4.0dBm
Wavelength: 1310nm
