Cisco QSFP-100G-4WDM-S Compatible 100GBASE-4WDM-10 QSFP28 Optical Transceiver Module for Ethernet and Data Center (SMF, 1271nm, 1291nm, 1311nm and 1331nm, 10km, LC, DOM)

Application: 100GBASE Ethernet, Data Center
CDR: TX and RX
Cisco Compatible: QSFP-100G-4WDM-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 3.5dB
Form Factor: QSFP28
Max Cable Distance: 10km@SMF
Max Data Rate: 103.1 Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: COB (chip on board) Packaging
Powerbudget: 6.5dB
Power Consumption: 3.5W
Protocols: QSFP28 MSA Compliant
Receiver Sensitivity: <-11.5dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 3.0dB
Transmitter Type: DML CWDM
TX Power: -6.5~2.5dBm
Wavelength: 1271nm, 1291nm, 1311nm and 1331nm
