Cisco QSFP-100G-ER4L-S Compatible 100GBASE-ER4 QSFP28 Optical Transceiver Module for Ethernet and Data Center (SMF, 1310nm, 40km, LC, DOM)

Application: 100GBASE Ethernet, Data Center
CDR: TX and RX
Cisco Compatible: QSFP-100G-ER4L-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC Duplex
DDM/DOM: Supported
Extinction Ratio: 4dB
Form Factor: QSFP28
Max Cable Distance: 25km-40km@SMF*
Max Data Rate: 103.1Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 18dB
Power Consumption: 4.5W
Protocols: QSFP28 MSA Compliant
Receiver Sensitivity: <-18.65dBm
Receiver Type: APD
Transmit and Dispersion Penalty: 2.5dB
Transmitter Type: 4x EML
TX Power: -2.9~4.5dBm
Wavelength: 1310nm
