Cisco QSFP-100G-LR4-D20 Compatible 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate Optical Transceiver Module for Telecom (SMF, 1310nm, 20km, LC, DOM)

Application: 100GBASE Ethernet, Telecom, 5G Network Mid/Backhaul
CDR: TX and RX
Cisco Compatible: QSFP-100G-LR4-D20
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
Data Rate: Dual Rate 103.1Gbps and 112Gbps
DDM/DOM: Supported
Extinction Ratio: 4dB
Form Factor: QSFP28
Max Cable Distance: 20km@SMF
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 1dB
Power Consumption: 3.5W
Protocols: 100G Ethernet, 25G Ethernet, OTN OTU4 4I1-9D1F
Receiver Sensitivity(100G): <-9.5dBm
Receiver Sensitivity(112G): <-9.0dBm
Receiver Type: 4 x PIN ROSA
Transmit and Dispersion Penalty: 2.2dB
Transmitter Type: 4 x LAN WDM DML TOSA
TX Power(100G): -1.0~4.5dBm
TX Power(112G): 0~4dBm
Wavelength: 1310nm*
