Cisco QSFP-100G-LR4-S Compatible 100GBASE-LR4 QSFP28 Optical Transceiver Module for Data Center, Ethernet and Telecom (SMF, 1310nm, 10km, LC, Industrial, DOM)

Application: 100GBASE Ethernet, Telecom, 5G Wireless Network
CDR: TX and RX
Cisco Compatible: QSFP-100G-LR4-S
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 4dB
Form Factor: QSFP28
Industrial Temperature Range: -40 to 85°C (-40 to 185°F)
Max Cable Distance: 10km@SMF
Max Data Rate: 103.125Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 8.5dB
Power Consumption: 4W
Protocols: IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm, QSFP28 MSA Compliant
Receiver Sensitivity: <-10.6dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 2.2dB
Transmitter Type: LAN WDM EML
TX Power: -4.3~4.5dBm
Wavelength: 1310nm*
