Cisco QSFP-100G-LR4-S Compatible 100GBASE-LR4 QSFP28 Optical Transceiver Module for Ethernet and Data Center (SMF, 1310nm, 10km, LC, DOM)

Application: 100GBASE Ethernet, Data Center
CDR: TX and RX
Cisco Compatible: QSFP-100G-LR4-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 4dB
Form Factor: QSFP28
Max Cable Distance: 10km@SMF
Max Data Rate: 103.125Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: COB (chip on board) Packaging
Powerbudget: 8.5dB
Power Consumption: 4W
Protocols: IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm, QSFP28 MSA Compliant
Receiver Sensitivity: <-8.6dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 2.2dB
Transmitter Type: 4 x LAN WDM DFB
TX Power: -4.3~4.5dBm
Wavelength: 1310nm*
