Cisco QSFP-100G-PSM4-S Compatible 100GBASE-PSM4 QSFP28 Optical Transceiver Module for Ethernet and Data Center (SMF, 1310nm, 500m, MTP/MPO, DOM)

Application: 100GBASE Ethernet, Data Center
CDR: TX and RX
Cisco Compatible: QSFP-100G-PSM4-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: MTP/MPO-12
DDM/DOM: Supported
Extinction Ratio: 3.5dB
Form Factor: QSFP28
Max Cable Distance: 500m@SMF
Max Data Rate: 103.1 Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: COB (chip on board) Packaging
Powerbudget: 3.2dB
Power Consumption: 3.5W
Protocols: QSFP28 MSA Compliant
Receiver Sensitivity: <-12.66dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 2.9dB
Transmitter Type: 4x DFB
TX Power: -9.4~2dBm
Wavelength: 1310nm
