Cisco QSFP-100G-SR4-S Compatible 100GBASE-SR4 QSFP28 Optical Transceiver Module for Data Center, Ethernet and Telecom (MMF, 850nm, 100m, MTP/MPO, DOM)

Application: 100GBASE Ethernet, Data Center
CDR: TX and RX
Cisco Compatible: QSFP-100G-SR4-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: MTP/MPO-12
DDM/DOM: Supported
Extinction Ratio: 3dB
Form Factor: QSFP28
Max Cable Distance: 70m@OM3/100m@OM4
Max Data Rate: 103.1 Gbps
Media: MMF
Modulation Format: NRZ
Packaging Technology: COB (chip on board) Packaging
Powerbudget: 1.9dB
Power Consumption: 3.5W
Protocols: QSFP28 MSA Compliant
Receiver Sensitivity: <-10.3dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 5dB
Transmitter Type: VCSEL 850nm
TX Power: -8.4~2.4dBm
Wavelength: 850nm
