Cisco QSFP-40G-ER4 Compatible 40GBASE-ER4 QSFP+ Optical Transceiver Module for Ethernet and Data Center (SMF, 1310nm, 40km, LC, DOM)

Application: 40GBASE-ER4 40G Ethernet, OTU3, OTU3e1, OTU3e2, Data Center
CDR: None
Cisco Compatible: QSFP-40G-ER4
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 5.5dB
Form Factor: QSFP+
Max Data Rate: 44.6Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 18.5dB
Power Consumption: 3.5W
Protocols: OTN OTU3, 40G Ethernet, Infiniband, Fiber Channel, SATA/SAS3, MSA Compliant
Receiver Sensitivity: <-21.2dBm
Receiver Type: APD
Transimitter Type: DFB CWDM
Transmit and Dispersion Penalty: 2.6dB
TX Power: -2.7~+4.5dBm
Wavelength: 1310nm
