Cisco QSFP-40G-SR4-S Compatible 40GBASE-SR4 QSFP+ Optical Transceiver Module for Ethernet and Data Center (MMF, 850nm, 150m, MTP/MPO, DOM)

Application: 40GBASE Ethernet, Breakout to 4 x 10GBASE Ethernet, Data Center
CDR: None
Cisco Compatible: QSFP-40G-SR4-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: MTP/MPO
DDM/DOM: Supported
Extinction Ratio: 3dB
Form Factor: QSFP+
Max Data Rate: 42Gbps
Media: MMF
Modulation Format: NRZ
Packaging Technology: COB (chip on board) Packaging
Powerbudget: 3.5dB
Power Consumption: 1.2W
Protocols: 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba, MSA Compliant
Receiver Sensitivity: <-11.1dBm
Receiver Type: PIN
Transimitter Type: VCSEL 850nm
Transmit and Dispersion Penalty: 3.5dB
TX Power: -7.6~1dBm
Wavelength: 850nm
