Cisco SFP-25G-SR-S Compatible 25GBASE-SR SFP28 Optical Transceiver Module for Data Center and Telecom (MMF, 850nm, 100m, LC, DOM)
Cisco SFP-25G-SR-S Compatible 25GBASE-SR SFP28 Optical Transceiver Module for Data Center and Telecom (MMF, 850nm, 100m, LC, DOM)
Ordinarie pris
1 248 SEK
Ordinarie pris
Försäljningspris
1 248 SEK
Enhetspris
/
per
Skatter ingår.
Det gick inte att ladda hämtningstillgänglighet
Application: 25GBASE Ethernet, Data Center, Telecom
CDR: TX and RX
Cisco Compatible: SFP-25G-SR-S
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 2dB
Form Factor: SFP28
Max Cable Distance: 100m @ OM4 MMF, 70m @ OM3 MMF
Max Data Rate: 25.78Gbps
Media: MMF
Modulation Format: NRZ
Packaging Technology: TO Packaging
Powerbudget: 5.3dB
Power Consumption: 1W
Protocols: MSA Compliant, CPRI, eCPRI
Receiver Sensitivity: <-10.3dBm
Receiver Type: PIN
Transmit and Dispersion Penalty: 3dB
Transmitter Type: VCSEL 850nm
TX Power: -5~2.4dBm
Wavelength: 850nm
