Cisco WSP-Q40GLR4L Compatible 40GBASE-LR4L QSFP+ Optical Transceiver Module for Ethernet and Data Center (SMF, 1310nm, 2km, LC, DOM)

Application: 40GBASE-LR4 40G Ethernet, Data Center
CDR: None
Cisco Compatible: WSP-Q40GLR4L
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Connector: LC duplex
DDM/DOM: Supported
Extinction Ratio: 3.5dB
Form Factor: QSFP+
Max Cable Distance: 2km@SMF
Max Data Rate: 41.2Gbps
Media: SMF
Modulation Format: NRZ
Packaging Technology: BOX Packaging
Powerbudget: 4.5dB
Power Consumption: 3.5W
Protocols: 40G Ethernet, Infiniband FibreChannel, SATA/SAS3, MSA Compliant
Receiver Sensitivity: <-11.5dBm
Receiver Type: PIN
Transimitter Type: DFB CWDM
Transmit and Dispersion Penalty: 2.6dB
TX Power: -7~2.3dBm
Wavelength: 1310nm
